Female 4 Holes 50Ω Impedance Flange Mount SMA RF Connector/RF Coaxial Connector

Name: Female 4 Holes 50Ω Impedance Flange Mount SMA RF ConnectorRF Coaxial Connector
Brand: ELT (Elite)
Price: 1 USD

Quality Female 4 Holes 50Ω Impedance Flange Mount SMA RF Connector/RF Coaxial Connector wholesale

Brand Name : ELT (Elite)

Model Number : SMA-KFD75

Certification : ROHS, ISO-9001-2015

Place of Origin : China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T, Western Union, L/C

Supply Ability : 1,000,00 Pieces Per Month

Delivery Time : Within 3-4 weeks

Packaging Details : Standard Export Carton

Product name : SMA RF Conector

Plating : Gold Plated

Gender : Female

Impedance : 50Ω

Frequency : DC~18GHz

Durability : 500 Cycles

Application : Communication

Model : SMA-KFD75

Contact Now

Female 4 Holes 50Ω Impedance Flange Mount SMA RF Connector/RF Coaxial Connector

1. SMA RF connectors are available in quick connect, straight, 90 degrees versions as well as bulkhead or 4 holes panel configurations.
2. SMA RF connector is high quality and quick combinations by simply screwing 2 connectors together with no soldering or crimping required.
3. SMA RF connectors are widely used for microwave, antennas and testing instrumentation etc.
4. SMA RF connector are threaded-coupling with miniature size, vibration-proof and wide frequency range up to 18GHz .

Specifiacation:

Interface according to	IEC60169-15
Impedance	50Ω
Freqency Range	DC to 18GHz
Insertion Loss	≤0.30dB
VSWR	≤1.2(DC-6GHz)
Insulation Resistance	≥5000MΩ
Center Contact Resistance	≤3mΩ
Outer Contact Resistance	≤2mΩ
Mating Cycles	≥500
Temperature Range	-65-+165℃
Dielectric	PTFE

Application:

* Broadband
* Instrumentation

* Base Station

* Mobile communication

* Outdoor facilities

* Radar,microwave

* Phased array antennas
* Telecommunications

* Board-to-board interconnect

Product Cataloge:

RF Adapter

SMA/SSMA RF Connector

SMP/SSMP RF Connector

TNC RF Connector

N Type RF Connector

MCX/MMCX RF Connector

BNC RF Connector

RF Cable Assemblies

Waveguide to Coaxial Adapter

Glass-to-metal Hermetic Seals

J30J Series Connector

Microwave Rotary Joints

Female 4 Holes 50Ω Impedance Flange Mount SMA RF Connector/RF Coaxial Connector

More Detail of Female 4 Holes 50Ω Impedance Flange Mount SMA RF Connector/RF Coaxial Connector:

Female 4 Holes 50Ω Impedance Flange Mount SMA RF Connector/RF Coaxial Connector

NOTE:
We have over 10,000 types of SMA Connector, if the connector you are using is not found, please contact us with your details.
